ModuRa-01 is a versatile RS-485 to LoRaWAN
device designed for easy sensor integration. It enables
wireless communication over long distances via LoRaWAN
technology. Supporting both Class A and Class C modes, the
ModuRa-01 can operate for over a year on battery power
without requiring any replacement. It supports a variety of
sensor types, including Proximity, Power, Flow, Pressure,
and Temperature sensors.
Easy sensor integration through RS-485
Long battery life of over a year
Supports LoRaWAN Class A and Class C
ModuRa-01 offers a robust set of features
for industrial sensor connectivity and remote monitoring.
With its IP68-rated enclosure, it is highly durable for
outdoor applications.
LoRaWAN Support: Operates in Class A and Class C modes
with AS923 frequency
Modbus RTU (RS485): Supports multiple functions such as
Coil, Discrete Inputs, and Holding Registers
Analog Inputs: 0-10V / 4-20mA with a resolution of 12 bits
GPIO: Up to 3 channels for INPUT, OUTPUT, and Counter
functions
Power Output: Provides 5V/9V/12V outputs for sensors, with
a maximum current of 100mA
Durability: IP68-rated for dust and water protection
ModuRa-01 is suitable for a wide range of
industrial and environmental applications, where reliable
and wireless data transmission is crucial.
Remote Sensor Monitoring: Suitable for long-distance data
collection and monitoring
Factory and Utilities Management: Ideal for automation and
smart system integration
Industrial Automation: Streamline operational data
collection in industrial settings
Environmental Monitoring: Use for monitoring environmental
conditions such as temperature and humidity
